IMPLEMENT WHEELS
IMPLEMENT WHEELS
“Feel where traction goes hand in hand with comfort.”
- A wide range of sizes - Meet the needs of a wide variety of the agricultural and municipal machines.
- Unmatched Load Capacity – Engineered for maximum strength, outperforming competitors.
- Ultra-Durable Discs – Precisely manufactured up to 20mm thick for failure-free performance.
- Custom Colors – Full RAL palette and OEM-specific colors available on request.
Tires are the essential point of contact between your car and the road. We work to ensure that your tires will always offer excellent braking, maximum safety, and pure driving pleasure.
Technical detalis
UNIGLORY R&D teams have dedicated over a decade to developing high-strength wheel rims for superior durability in agricultural and industrial applications.
- High-Strength Steel Construction ： Precision-engineered rims using premium steel alloys enhance load-bearing capacity and impact resistance.
- Advanced Welding & Forming Technology ： Automated manufacturing ensures structural integrity, reducing weak points and increasing lifespan.
- Optimized Disc Design ： Thickened disc structures and reinforced bead seats provide exceptional strength in high-stress environments.
- Enhanced Corrosion Resistance ： A multi-layer powder coating process offers long-lasting protection against rust, chemicals, and harsh weather.
- Precision Balancing ： Engineered for uniform weight distribution, minimizing vibration and improving operational stability.
The results are the outstanding service life of agriculture & industrial wheels, increased by more than 30%.
| Wheel Dia.（in） | Rim profile | Tyre sizes | Maximum load capacity (kg) at 40 km/h | Maximum speed ( km/h) | Maximum offset ranges (mm) |
|---|---|---|---|---|---|
| 12” | 4.25x12 | 7.00-12 | 950 | 40 | +38/-44(wentylem do maszyny |
| 12” | 5JAx12 | 6.5/80-12 | 950 | 40 | +47/-53(wentylem do maszyny) |
| 12” | 7.00x12 | 10.0/80-12 | 950 | 40 | +64/-70 |
| 15” | 9.00x15 | 10.0/75-15.3; 11.5/80-15.3 | 1750 | 40 | +99/-105 |
| 15,3” | 9.00x15.3 | 10.0/75-15.3; 10.0/80-12; 11.5/80-15.3; 12.5/80-15.3; 260/70-15.3 | 3000 | 40 | +105/-113 |
| 15.5” | 13.00x15.5 | 400/60-15.5 | 3500 | 40 | +152/-160 |
| 15.5” | 13.00x15.5H2 | 400/60-15.5 | 3300 | 40 | +152/-160 |
| 16” | 4.50Ex16 | 6.00-16 | 870 | 40 | +53/-59(wentylem do maszyny) |
| 16” | 5.50Fx16 | 7.50-16 | 870 | 40 | +56/-62 |
| 16” | 9.00x16 | 10.5/65-16 | 2350 | 40 | +104/-110 |
| 16” | 11x16 | 13.0/55-16; 13.0/75-16; 14.0/65-16 | 3000 | 40 | +127/-133 |
| 17” | 13.00x17 | 15.0/55-17; 420/55-17 | 3350 | 40 | +144/-154 |
| 17” | 16.00x17 | 19.0/45-17; 500/50-17; 500/65-17 | 4750 | 40 | +182/-192 |
| 17” | 16.00x17 | 19.0/45-17; 500/50-17; 500/65-17 | 4750 | 40 | +182/-192 |
| 18” | 5.50Fx18 | 7.50-18 | 1250 | 40 | +60/-68 (with valve guard on the machine’s side) |
| 18” | 9.00x18 | 10.5/80-18; 12.0/75-18; 12.5/80-18 | 3500 | 40 | +75/-85 |
| 18” | W9x18 | 10.5/80-18; 12.0/75-18; 12.5/80-18 | 3075 | 40 | +43/-53 |
| 18” | 11x18 | 12.0-18; 12.5/80-18; 13.0/65-18; 14.5/80-18 | 3800 | 40 | +98/-108 |
| 18” | 13x18 | 400/60R18; 15.0/70-18 | 3800 | 40 | +124/-134 |
| 20” | 13x20 | 16.0/70-20 | 3500 | 40 | +147/-157 |
| 22.5” | 16.00x22.5 | 500/45 R22.5;500/50R22.5; 500/60-22.5;500/60 R22.5; 550/45-22.5;550/60-22.5; 560/45R22.5;560/60R22.5 | 6500 | 40 | +176/-190 (with valve guard on the machine’s side) |
| 24” | W12 | 15.5/80-24 | 4700 | 40 | +143/-153 |
| 24” | W13 | 15.5/80-24; 16.5/85-24; 400/80-24 | 4700 | 40 | +155.5/-165.5 |
| 24” | W14L | 15.5/80-24 | 4700 | 40 | +160/-170 |
| 24” | W15L | 17.5L-24 | 4700 | 40 | +172/-182 |
